20kVA Zone 2 Diesel Engine Generator /Zone II Genset

20 kVA ATEX Zone 2 diesel generator featuring a ComAp MRS16 microprocessor controller with PLC logic, automatic protection, event history, fault diagnostics, and remote monitoring and control.

  • ATEX Zone 2 certified Perkins engine
  • Electronic governor
  • Dual Nicd battery
  • Microprocessor based genset controller
  • Built-in PLC logic
  • Remote monitoring and control
  • Automatic protection and shutdown
  • Event history and fault diagnostics
  • Modbus and J1939 communication
  • Suitable for offshore applications
ATEX Directive 2014/34/EU, IECEx Certificate of Conformity

Request a Quote

Need help first? Contact chao.kuang@sunexeu.com; joann.wang@sunexeu.com

Overview

The SunEx 20 kVA Zone 2 diesel generator pairs a Perkins 404D-22 engine with a MECC ALTE TE 34-1S/4 alternator and ComAp MRS16 microprocessor controller, delivering ATEX/IECEx certified hazardous-area power in a compact continuous-duty package. Built for smaller oil & gas, offshore and petrochemical sites that don't need the full 20-2000 kVA range, it ships with automatic protection, event history, fault diagnostics and remote monitoring as standard.

Dimensions: 2600L x 1800W x2200H mm

Specifications

Rated Power20 kVA / 20.6 kWm
EnginePerkins 404D-22
AlternatorMECC ALTE TE 34-1S/4
ControllerComAp MRS16
Voltage / Frequency400/230V / 50Hz
Phase3 Phase 4 Wire
Rated Current29 A
IP RatingIP23 (Alternator: IP55)
Hazardous Area ClassificationZone 2
DutyContinuous

20 kVA Zone 2 Diesel Engine Generator | Zone II Genset

20 kVA Generator Technical Data

RATED POWER : 20 kVA

POWER FACTOR : 0.8

RATED VOLTAGE : 400/230 V AC

RATED CURRENT : 29 A

RATED FREQUENCY : 50 Hz

DUTY : CONTINUOUS

PHASE : 3 PHASE 4 WIRE

IP RATING : IP23 (ALTERNATOR: IP55)

ENGINE / MECHANICAL DATA

ALTERNATOR DATA

MANUFACTURER

PERKINS

MANUFACTURER

MECC ALTE

MODEL NO.

404D-22

MODEL NO.

TE 34-1S/4

RATED POWER

20.6 kWm

RATED POWER

50 kVA

RATED SPEED

1500 RPM

POWER FACTOR

0.8

RADIATOR

RAD-G404D/201001

RATED VOLTAGE

400/230 V AC

DIESEL TANK

100 L

RATED FREQUENCY

50 Hz

DRY/WET WEIGHT

3230 KG / 3340 KG

RATED CURRENT

72 A

DIMENSIONS

2600L x 1800W x 2200H mm

AVR MODEL NO.

UVR6/1
zone 2 DEG, Zone 2 Diesel Engine generator, Zone 2 Gas Engine Generator, Zone 2 Rental. Sunex, ATEX generator.
